Primus HSM S-Series | PQC-Ready HSM for Swiss Payment Security

The HSM protecting the Swiss Interbank Clearing system

Securing the Swiss financial market and ensuring that funds are placed properly pose significant challenges. The IT infrastructure of the Swiss financial marketplace must adhere to the highest security standards to combat ever-growing threats. SIX Interbank Clearing manages the SIC interbank payment system, handling transactions worth around CHF 100 billion daily, along with the settlement of the SIX exchange.

Solution

To address these challenges, Primus S2-Series HSM has been specifically designed for the Swiss Interbank Clearing System operated by SIX SIC under the supervision of the Swiss National Bank.

These models are engineered to accommodate technological advancements and increased security and performance needs, crucial for the Swiss payment system. Primus S2-Series HSMs feature market-leading encryption and authentication performance, along with cryptographic algorithms that are secure against post-quantum computing threats. With this, Securosys and SIX underscore their dedication to fortifying the security and efficiency of Switzerland’s financial system.

There are three different models available:

The S4 Model for entry level performance requirements but without multi-tenant support
The S6 Model for medium level performance requirements and with multi-tenant support
The S6P Model for high level performance requirements and with multi-tenant support

All models are PQC ready and can be managed by the Decanus Remote Access Management Device.

Flexible partitioning ensures tailored key segregation for specific applications, enhancing management capabilities. Group multiple Primus HSMs for redundancy and load balancing through high availability clustering.

Bolster security with integrated two-factor authentication and tamper protection features, fortifying against unauthorized access and preserving the integrity of sensitive information.

Streamline device management securely and effortlessly using the Decanus Terminal.

Primus HSMs offer robust support for a wide range of cryptographic functions, including symmetric (AES) and asymmetric encryption (RSA, Diffie-Hellman, ECDSA), as well as hash algorithms (SHA-2, SHA-3), ensuring versatile cryptographic capabilities.

User-friendly interface that simplifies setup, commissioning, configuration, and maintenance processes, enhancing operational efficiency.

Seamlessly integrate with built-in high-availability clustering across data centres. Copper and 10Gbps optical interfaces, along with LACP interface bundling, facilitate effortless integration into any network environment

SIX-tailored Security

Engineered specifically for SIX, the backbone of the Swiss Interbank Clearing System, the Securosys Primus HSM S2-Series delivers tailored security solutions for Swiss interbank clearing and settlement operations, alongside safeguarding SECOM, the Swiss stock exchange.

Swiss Made

Crafted entirely in Switzerland, Securosys Primus HSMs embody unmatched quality and reliability. Free from external influences, our Swiss-made HSMs guarantee the highest standards from development to production, ensuring unparalleled security solutions.

Securing Swiss Financial Transactions

The Primus HSM S2-Series offers industry-leading performance tailored for securing financial transactions. It is ideal for critical operations such as SIC, eSIC, and SECOM transactions, providing robust security through key generation, management, authentication, and encryption tasks.

The Securosys HSMs that have been in use since 2016, will be replaced by the latest generation of HSMs, offering enhanced performance and protection against Post-Quantum Cryptography (PQC) threats.

Read the Press Release

Security Features

Networking Features

Technical Data

Security Features

Multi-barrier software and hardware architecture with supervision mechanism

128/192/256-Bit AES
with GCM-, CTR-, ECB-, CBC-, MAC Mode
Camellia, ChaCha20-Poly1305, ECIES
RSA 1024-8192, DSA 1024-8192
ECDSA 224-521, GF(P) arbitrary curves (NIST, Brainpool, ...)
ED25519, Curve25519
Diffie-Hellman 1024, 2048, 4096, ECDH
SHA-2/SHA-3 (224 - 512), SHA-1, RIPEMED-160, Keccak
HMAC, CMAC, GMAC, Poly 1305
Post-Quantum Cryptographic (PQC) algorithms CRYSTALS-Dilithium, CRYSTALS-Kyber, SPHINCS+

Two hardware true random number generators (TNRG)
NIST SP800-90 compatible random number generator

Key capacity: up to 12 GB
1 partitions @ 240 MB secure storage upgradeable to max. partitions:

S6P 50

S6 10

S4 1

Number of client connections not restricted

Several sensors to detect unauthorized access
Active destruction of key material and sensitive data on tamper
Transport and multi-year storage tamper protection by digital seal

Cryptographic evidence of audit relevant parameters (keys, configuration, hardware, states, logs, time-stamping)

Multiple security officers (m out of n)
Identification based on smart card and PIN

Networking Features

Technical Data

Model	RSA 4096	RSA 3072	ECC 521	ECC 384
S6P	1000	2000	800	2000
S6	500	1000	400	1000
S4	25	50	25	50

Two redundant power supplies, hot pluggable 100 ... 240 V AC, 50 ... 60 Hz
Power dissipation: 60 W (typ), 100 W (max)
Ultra capacitors for data retention
Backup lithium battery: Lithium Thionyl Chloride 0.65g Li, IEC 60086-4, UL 1642, 3.6V

4 Ethernet RJ-45 ports with 1 Gbps (rear)
2 SFP+ slots for optical 10Gbps Ethernet modules (rear)
2 Console ports (RJ45, front/rear)
2 USB-A management ports (front/rear)
1 USB-C management port (rear)
3 Smart card slots

3 slots for Securosys Security smart cards
4 LEDs for system and interface status (multicolor)
Touch screen for configuration
Console interface
Optional Decanus Terminal for remote administration

EMV/EMC: EN 55022, EN 55024, FCC Part 15 Class B
Safety: IEC 62368-1

Temperature ranges (IEC 60068-2-1 Ad, IEC 60068-2-2 Bd): storage -20...+60 °C; operation 0...+35 °C
Humidity (IEC 60068-2-78 Cab):
40 °C, 93% RH, non-condensing
MTBF (RIAC-HDBU-217Plus) at tamb=25 °C: >100 000 h
Dimensions (w×h×d) 417×44×365 mm
(1U 19" EIA standard rack)
Weight 7.5 kg
